Claber 90829 Hydro 4

Pick Up & Delivery Options
  • ready to use
  • battery-operated
  • for the most common gardens (up to 700 sq.m.)
  • iP68 rating valve box and water timer
  • versatile programming with only 3 keys and large display
  • fitted for radio frequency connection with Rain Sensor RF
  • A practical, ready-to-use solution to manage irrigating the most common gardens (up to about 700 sq.m.) with extreme versatility and reliability. Hydro-4 is a valve box with IP68 rating, the maximum protection against water, moisture and dust, containing a battery water timer and 4 solenoid valves. Thanks to its compact dimensions, Hydro-4 is easily buried and can be used even above ground. Connecting to the water connector and the irrigation system is extremely simple and does not even require electrical connections. Hydro-4 is compatible with 1/2" main hoses, push-in couplings and Colibr micro-sprinklers, or with 20mm main hoses, Quick-Click couplings and medium jet range pop-ups. In addition, it can also be connected to a drip irrigation line or to a dripper hose. You can manage up to 4 independent irrigation lines to satisfy all your irrigation needs for lawns, flower beds, potted plants, bushes and vegetable gardens.

  • Preassembled valve box incorporating the timer. Power provided by two 1.5V AAA batteries, enough to last an entire season. On/off control for up to 4 independent underground or drip irrigation lines. Easy programming procedure, using just 3 buttons and a large size display. Watering time 1 to 60 minutes. 2 programs for each outlet, up to 4 watering cycles per day. Weekly setting, allowing exclusion of single days. Manual test of 5 minutes duration, variable in the same way as for watering times. A perfectly sealed IP 68 unit. Protective cover and buttons in bi-material rubber. Facility of viewing and deleting programs entered for each line. 3/4"� M connections on both inlet and outlet sides. Wireless connection to radio frequency Rain Sensor. 2 threaded caps provided for unused outlets. 4 solenoids valves. Watering line flow rates: 25 l/min at 2.5 bar Operating pressure: 0.2 - 12 bar. Operating temperature: 3 - 60 °C. Dimensions: diameter 200 - height 153 mm.

    • Inlet thread: ¾"
    • Outlet thread:¾"
    • Adjustment: open/close
    • Water flow: 25 l/min
    • Pressure: 2,5 bar
    • Voltage: 3V
    • Outlets: 4
    • Programmes: 2
    • Frequency of watering cycles:8 per day
    • Watering duration: da 00:01' a 01:00'
    • Rain sensor: wireless
    • Powered by: 2xAAA
    • Warranty: 2 years
